196K83-1 Goodyear Flight Leader DT Three-Part Aircraft Tire | 19.5×6.75-8, 8 Ply, TL (Tubeless) | 196K831
- Ply Rating: 8
- TT or TL: TL (Tubeless)
- Rated Speed (MPH): 210
Please consult the following documents for more information about the 196K83-1 Goodyear Flight Leader DT Three-Part Aircraft Tire:
CONSTRUCTION
- Ply Rating: 8
- TT or TL: TL (Tubeless)
- Rated Speed (MPH): 210
SERVICE RATING
- Rated Load (LBS): 3,300
- Rated Inflation (PSI): 86
- Maximum Braking Load (LBS): 4,950
- Maximum Bottoming Load (LBS): 9,900
INFLATED DIMENSIONS
- Outside diameter: Max 19.5 / Min 18.9
- Section width: Max 6.75 / Min 6.2
- Shoulder: Diameter Max 17.45 / Width Max 5.95
- Static Loaded Radius (inches): 8.05
- Flat Tire Radius (inches): 5.90
- Aspect ratio: 0.865
WHEEL
- Width Between Flanges: 5.25
- Specified Rim Diameter: 8
- Flange Height: 0.81
- Minimum Ledge Width: 1.25
| Dimensions | 00 × 00 in |
|---|
